Yamaha F200 2023

Description

Yamaha’s popular and proven range of F200 Digital and Mechanical Control outboards now feature a newly designed look and integrated steering, taking these engines to the next level when it comes to power, reliability and control.



Boat owners can now choose from Integrated Hydraulic Steering or Integrated Electro-Hydraulic Steering, with both systems housed in a neat, sealed cylinder unit, which is built into the transom bracket of the engine, rather than being a third-party bolt-on component. This results in a simple and clean rigging set-up, and an uncluttered bilge and transom area, while exposing less components to the elements for improved long-term durability and reliability.



The Integrated Electro-Hydraulic Steering models are fully compatible with Yamaha’s exclusive Helm Master EX Autopilot and Joystick system, a must have system for serious fishermen and skippers who demand ultimate boat control.

This new range of four-cylinder integrated steering models are ideal for all applications, including new boat packages, existing boat repowers and multi engine set-ups.

Available in signature Yamaha grey and pearlescent white, the modernised F200 outboards bring a new level of delight to boating.



MODELS F200SA F200CB F200C
Control System Digital Electronic Control (DEC) Digital Electronic Control (DEC) Mechanical Control (MEC)
Steering System Integrated Electro-Hydraulic Steering (IEHS) Integrated Hydraulic Steering (IHS) Integrated Hydraulic Steering (IHS)
Colour Yamaha Grey or Pearl White  Yamaha Grey Yamaha Grey
Helm Master EX Autopilot/Joystick Compatible Yes - -
Counter Rotating Yes - Yes
Transom Height (Shaft Length) mm [inch] X: 642 [25.3] L: 516 [20.4] | X: 642 [25.3] L: 516 [20.4] | X: 642 [25.3]
Colour:
Pearlescent White, Yamaha Grey
Make:
Yamaha
Model:
F200
Condition:
New
Year:
2023

Enquiry

Features


Integrated Hydraulic Steering

Integrated Hydraulic Steering

Featuring the same streamlined look as the Electro-Hydraulic Steering model, these models combine conventional hydraulic helm and lines with a built-in hydraulic cylinder. Simple in design yet offering all the space-saving, premium benefits of integrated steering, this system offers a fresh look and smooth, precise non-powered control. As the hydraulic lines are connected directly to the fixed bracket and steering cylinder, there is none of the usual wear and tear that is seen on traditional hydraulic systems. Hydraulic helm and lines purchased separately.

New Look cowling and Colour Options

New Look cowling and Colour Options

The cowling has been completely redesigned for a more powerful, elegant and streamlined look. Integrated Electro-Hydraulic Steering models also offer the choice of signature Yamaha grey or pearlescent white finish, with premium looking raised chrome Yamaha graphics. Integrated Electro-Hydraulic model shown.

Helm Master EX Prop Light

Helm Master EX Prop Light

This optional feature is available to Integrated Electro Hydraulic Steering outboard models that are matched with Yamaha's exclusive Helm Master EX joystick boat control system. The light mounts directly in the rear apron of the outboard, providing a visual warning that the boat is actively in one of the Helm Master EX SetPoint modes.

2.8 Litre Four-Cylinder Engine

2.8 Litre Four-Cylinder Engine

The 16 valve, 2.8 litre, double overhead camshaft (DOHC) layout with its increased cylinder capacity and large valves, results in optimum valve actuation, resulting in improved valve timing, acceleration and overall running performance.

Digital Electronic Control - Single Binnacle

Digital Electronic Control - Single Binnacle

Completely redesigned with greater ergonomic comfort and new capabilities, including: Speed Control (push-button up or down), Pattern Shift (for slower than idle speed trolling), Neutral Hold (for engine warm up or additional charge for batteries), Station Selector (for selector more then one helm) and Engine Trim. Available for DEC engines only.

Tilt Limiter

Tilt Limiter

Available on Mechanical Control (MEC) outboard models, the built-in tilt limiter function automatically stops the engine tilt at a predetermined set point, preventing the outboard cowling from hitting objects such as bait boards or other parts of the boat.

Integrated Electro-Hydraulic Steering

Integrated Electro-Hydraulic Steering

Fully integrated into the outboard bracket, this 'steer-by-wire' system is exceptionally smooth, responsive and feature rich, with the ability to work with Yamaha's exclusive Helm Master™ EX Autopilot and Joystick system. The streamlined and compact design provides more bilge, engine well, and transom space than conventional steering systems and because it is Yamaha engineered, delivers exceptional performance and reliability. This engine comes with an electro helm. Available on select models only.

704 Premium Single Binnacle Control

704 Premium Single Binnacle Control

This highly-polished, stylish looking, top mounted control allows for effortless one-handed control. The ergonomic design features a thumb operated trim and tilt switch built into the handle, as well as shift and throttle control functions, for convenient and comfortable operation. Available for MEC engines only.

704 Premium Twin Binnacle Control

704 Premium Twin Binnacle Control

This highly-polished, stylish looking, top mounted control allows for effortless operation of twin mounted outboards. The ergonomic design features a thumb operated trim and tilt switches built into the handles, as well as shift and throttle control functions, for convenient and comfortable operation. Available for MEC engines only.

Yamaha Shift Dampener System

Yamaha Shift Dampener System

Many of Yamaha's mid-range and high horsepower props come with Yamaha’s exclusive Shift Dampener System (SDS). This system absorbs forces created when an engine shifts in and out of gear, resulting in a quieter, smoother and ‘clunk free’ shifting.

Single Binnacle Digital Control

Single Binnacle Digital Control

This highly polished, ergonomic, top mounted control offers an extremely smooth and effortless one-hand operation of throttle, shift functions and trim and tilt. The digital electronic control ‘drive-by-wire’ system eliminates the need for mechanical control cables, reducing installation time and costs. F200CA models.

Genuine Yamaha Propellers

Genuine Yamaha Propellers

Prop choice makes a huge difference to outboard acceleration, top-end speed, handling and fuel efficiency. That is why Yamaha continues to push the technological boundaries in the design and development of our leading range of high performance props - ensuring every Yamaha outboard performs at its peak.

Reliance SDS Series

Reliance SDS Series

This new line-up of polished stainless steel props are specifically designed for Yamaha's powerful inline four-cylinder engines. They include Yamaha’s Shift Dampener System (SDS) for quieter and smoother shifting, without the ‘clunk’ normally associated with shifting gear.

Saltwater SDS

Saltwater SDS

These stainless-steel propellers are renowned for their durability and superior mid-range fuel efficiency on large offshore boats - while their excellent anti-ventilation characteristics deliver improved handling in rough seas. This prop incorporates Yamaha's Shift Dampener System (SDS) for quieter and smoother shifting.

TotalTilt™ with Tilt Limiter

TotalTilt™ with Tilt Limiter

Available on Digital Electronic Control (DEC) models, Yamaha’s exclusive TotalTilt™ feature provides faster and easier engine tilting, by completely tilting the outboard up from any position with a simple double-push of the “UP” trim/tilt button, or fully tilting the outboard down (until trim ram contact) with a double-push of the “DOWN” trim/tilt button. This system also includes a built-in tilt limiter which automatically stops the engine tilt at a predetermined set point, to prevent engine contact with other objects.

Digital Electronic Control - Twin Binnacle

Digital Electronic Control - Twin Binnacle

In addition to all the features on the single handle digital electronic control, the twin handle control also provides: Single Lever control (for controlling multiple engines with one lever), Centre Engine select (for selecting the centre engine only on triple and quad outboard set-ups) and the ability to Trim all or each individual engine separately. Available for DEC engines only.

6x3 Concealed Side-Mounted Control

6x3 Concealed Side-Mounted Control

With its stylish chrome finish and ergonomic design, this mechanical control not only looks good, but provides effortless one-hand operation. The trim and tilt switch is comfortably located on the handle and features easily accessible neutral warm-up controls and externally adjustable throttle friction. Available for MEC engines only.

703 Side-Mounted Control

703 Side-Mounted Control

One of Yamaha's best selling controls, this mechanical remote offers comfort, simplicity and flexibility. With its new ergonomic grip, reversible right-hand or left-hand installation, and convenient trim and tilt operation, this control offers all-round functionality and value. Available for MEC engines only.

Remote Control Security System

Remote Control Security System

Yamaha's optional Customer Outboard Protection (Y-COP) engine immobiliser system is easy to use and highly effective in stopping unauthorised start-ups when your boat is unattended. Simply push the button on the neat and simple remote to lock and unlock the engine.

CL5 Premium Touchscreen Display

CL5 Premium Touchscreen Display

The all-new, low profile Yamaha Command Link CL5 touchscreen display is small in size but big on information, features and capability.

This display is suitable for all Yamaha Electronic Fuel Injected (EFI) engines and can monitor up to four outboards. It's sophisticated, modern design features intuitive operation and matches the latest boat console trends, while its compact size leave more room on the console for other electronics.

Command Link - 6Y8 Round Gauge

Command Link - 6Y8 Round Gauge

Using Local Area Network (LAN) technology, these digital round gauges provide accurate and real-time tachometer, speed and fuel management stats, including fuel flow/consumption/economy (up to two tanks), trim level, battery voltage, push button trolling speed adjustments and more.

Variable Trolling Control

Variable Trolling Control

Yamaha’s variable trolling control allows the skipper to precisely adjust the engine’s idling speed from 650 to 900 RPM in 50 RPM increments. The ability to finely tune the trolling speed allows fisherman to perfect their lure presentation when chasing different species of fish.

Digital Boat Control System

Digital Boat Control System

Helm Master® EX is an industry-first fully integrated digital boat control system that delivers next level control over your boat for increased boating and fishing enjoyment. Now available for single and multiple outboard engine applications (DEC models only).

Shift Dampener System

Shift Dampener System

Yamaha's Shift Dampener System (SDS) propellers greatly reduce the noise associated with shifting an engine in and out of gear by absorbing the forces generated when forward and reverse gears are engaged.

Conventional - 6Y5 Round Gauge

Conventional - 6Y5 Round Gauge

Yamaha’s most affordable Tachometer and Speedometer gauges offer RPM, Trim Angle, Oil Pressure, Overheat Warning, Trip Hours, Total Operating Hours, Speed, Trip Distance, Time, Fuel Level, Low-Fuel Warning and Battery Voltage/Warning.

Offset Crankshaft

Offset Crankshaft

The crankshaft design is offset 10mm from the centre of cylinder for more efficient transfer of power to the crankshaft.





One-Touch Start-Stop for Multiple Engines

One-Touch Start-Stop for Multiple Engines

This optional system for twin and triple installations automatically synchronises engines to allow a simple one-touch starting/stopping button capability.

Electronic Throttle Valve

Electronic Throttle Valve

The electronic throttle valve provides sure and more precise valve opening and closing according to each engine temperature and atmospheric condition. This system works in tune with the fuel injection and ignition systems, to deliver incredible response and exceptional fuel economy.

High Output Alternator

High Output Alternator

This alternator delivers more power: 50 amps at wide open throttle, producing a full 22 amps at only 600 rpm which means there is sufficient output to keep charging the battery even at low RPM.

F200 Performance Data Reports

F200 Performance Data Reports

We take out the guess work in buying a new outboard, by rigorously testing our engines on Australia's most popular boat brands. See how the F200 performs for acceleration, fuel economy and top-end speed on your favourite boat.

Yamaha Outboard Tech

Yamaha Outboard Tech

Yamaha offers a range of rigging options to suit every boat. Check out the full suite of controls, gauges, switches, props and other technologies, plus outboard performance data.

Direct Ignition

Direct Ignition

The direct ignition system, with plug cap and ignition coil, provides higher reliability and increased performance.





Helm Master® EX Control System

Helm Master® EX Control System

Helm Master® EX is an industry-first fully integrated digital boat control system that delivers Autopilot and Joystick control over your boat for increased boating and fishing enjoyment. Now available for single and multiple outboard engine applications. Available with Integrated Electro-Hydraulic Steering models only.

Variable Camshaft Timing

Variable Camshaft Timing

The Variable Camshaft Timing (VCT) advances and retards the camshaft timing according to the engine RPMs. This in combination with the electronically controlled single throttle valve system and long intake manifold boosts low and mid-range torque for optimum acceleration.

Technical Specifications


Engine

Engine Type
4-Stroke, 16 Valve DOHC VCT Direct Action In-Line 4
Displacement (cc)
2785.0
Bore x Stroke (mm)
96 x 96.2
Lubrication System
Wet-sump
Fuel Management
EFI
Ignition
TCI
Starter System
Electric

Dimensions

Height (mm)
(L): 516 [20.4] (X): 642 [25.3]
Wet Weight (kg)
F200XSA: 238 | F200LCB: 235 | F200XCB: 236 | F200LC: 234 | F200XC: 235
